Product Series
UCFU Type
Square flanged ball bearing unit with set screw locking, cast iron. They consist of an insert bearing, with an extended inner ring and grub screw locking, suitable for applications where the direction of rotation is constant or alternating.
Key words:
Category:
Pillow Block Bearings
E-mail：
WhatsApp：
UCFU Type
Square flanged ball bearing unit with set screw locking, cast iron. They consist of an insert bearing, with an extended inner ring and grub screw locking, suitable for applications where the direction of rotation is constant or alternating. The bearing is mounted in a housing, which can be bolted to a machine wall or frame. Ball bearing units can accommodate moderate initial misalignment, but normally do not permit axial displacement.
|
Bearing Number |
d |
D |
B |
|
(mm) |
(mm) |
(mm) |
|
|
UCFU203 |
17 |
27.4 |
78 |
|
UCFU204 |
20 |
31 |
88 |
|
UCFU205 |
25 |
34.1 |
97 |
|
UCFU206 |
30 |
38.1 |
110 |
|
UCFU207 |
35 |
42.9 |
119 |
|
UCFU208 |
40 |
49.2 |
132 |
|
UCFU209 |
45 |
49.2 |
139 |
|
UCFU210 |
50 |
51.6 |
145 |
|
UCFU211 |
55 |
55.6 |
164 |
|
UCFU212 |
60 |
65.1 |
177 |
|
UCFU213 |
65 |
65.1 |
189 |
|
UCFU214 |
70 |
74.6 |
195 |
|
UCFU215 |
75 |
77.8 |
202 |
|
UCFU216 |
80 |
82.6 |
213 |
|
UCFU217 |
85 |
85.7 |
222 |
|
UCFU218 |
90 |
96 |
240 |
|
UCFU220 |
100 |
108 |
270 |
|
UCFU305 |
25 |
38 |
110 |
|
UCFU306 |
30 |
43 |
125 |
|
UCFU307 |
35 |
48 |
135 |
Last
Next
Last
UCT Type
Next
Advantages
The product is widely used as a supporting product in industries such as metallurgy, mining, petroleum, chemical, coal, cement, papermaking, wind power, heavy machinery, engineering machinery, agricultural machinery, port machinery, etc.
01
Suitable for mass production, with stable and reliable quality and high production efficiency
02
Standardized size, interchangeable, easy to install and disassemble, and easy to maintain
03
Compact structure, light weight, and reduced axial size
04
High precision, high load, low wear, and long service life
05
The starting friction torque is only slightly higher than the rotational friction torque
06
Suitable for mass production, with stable and reliable quality and high production efficiency
07
The transmission friction torque is much lower than that of hydraulic bearings, resulting in lower friction temperature rise and power consumption
08
Some bearings have automatic centering performance
Processing Factory
We have a complete and scientific quality management system, equipped with modern production equipment and advanced testing instruments
