Product Series
52000 Series
Double direction thrust ball bearings type 52000 can withstand axial thrust loads in two directions, and can limit the movement of the shaft and housing in one direction.
Key words:
Category:
Thrust Ball Bearings
E-mail：
WhatsApp：
52000 Series
Double direction thrust ball bearings type 52000 can withstand axial thrust loads in two directions, and can limit the movement of the shaft and housing in one direction. These bearings have a separable design for easy installation, removal and bearing inspection.
|
Bearing Number |
Dimensions （mm） |
|
52202 |
15(10)×32×22 |
|
52204 |
20(15)×40×26 |
|
52205 |
25(20)×47×28 |
|
52206 |
30(25)×52×29 |
|
52207 |
35(30)×62×34 |
|
52208 |
40(30)×68×36 |
|
52209 |
45(35)×73×37 |
|
52210 |
50(40)×78×39 |
|
52211 |
55(45)×90×45 |
|
52212 |
60(50)×95×46 |
|
52213 |
65(55)×100×47 |
|
52214 |
70(55)×105×47 |
|
52215 |
75(60)×110×47 |
|
52216 |
80(65)×115×48 |
|
52217 |
85(70)×125×55 |
|
52218 |
90(75)×135×62 |
|
52220 |
100(85)×150×67 |
|
52220M |
|
|
52222 |
110(95)×160×67 |
|
52224 |
120(100)×170×68 |
|
52224M |
|
|
52226 |
130(110)×190×80 |
|
52228M |
140(120)×200×81 |
|
52228 |
140(120)×200×81 |
|
52230 |
150(130)×215×83 |
|
52230M |
150(130)×215×89 |
|
52232 |
160(140)×225×90 |
|
52232M |
|
|
52234M |
170(150)×240×97 |
|
52234 |
170(150)×240×97 |
|
52236 |
180(150)×250×98 |
|
52236M |
|
|
52238 |
190(160)×270×109 |
|
52238J |
190(160)×270×109 |
|
52240 |
200(170)×280×109 |
|
52244 |
220×300×110 |
|
52305 |
25(20)×52×34 |
|
52306 |
30(25)×60×38 |
|
52307 |
35(30)×68×44 |
|
52308 |
40(30)×87×49 |
|
52309 |
45(35)×85×52 |
|
52310 |
50(40)×95×58 |
|
52311 |
55(45)×105×64 |
|
52312 |
60(50)×110×64 |
|
52313 |
65(55)×115×65 |
|
52314 |
70(55)×125×72 |
|
52315 |
75(60)×135×79 |
|
52316 |
80(65)×140×79 |
|
52317 |
85(70)×150×87 |
|
52318 |
90(75)×190×110 |
|
52320 |
100(85)×170×97 |
|
52322 |
110(95)×1490×110 |
|
52322M |
|
|
52324 |
120(100)×210×123 |
|
52324M |
|
|
52326M |
130(110)×225×130 |
|
52326 |
130(110)×225×130 |
|
52328 |
140(120)×240×140 |
|
52330 |
150(130)×250×140 |
|
52330M |
|
|
52332 |
160(140)×270×153 |
|
52334 |
160(140)×270×153 |
|
52336 |
180(150)×300×165 |
|
52338 |
190×320×183 |
|
52340 |
200×340×192 |
|
52405 |
25(15)×60×45 |
|
52406 |
30(20)×70×52 |
|
52407 |
35(25)×80×59 |
|
52408 |
40(30)×90×65 |
|
52409 |
45(35)×100×72 |
|
52410 |
50(40)×110×78 |
|
52411 |
55(45)×120×87 |
|
52411M |
|
|
52412 |
60(50)×130×93 |
|
52413 |
65(50)×140×101 |
|
52414 |
70(55)×150×107 |
|
52414M |
|
|
52415 |
75(75)×160×115 |
|
52416 |
80(68)×170×201 |
|
52417 |
85(65)×180×128 |
|
52417M |
|
|
52418 |
90(70)×190×135 |
|
52420M |
100(80)×210×150 |
|
52420 |
100(80)×210×150 |
|
52422 |
110(90)×230×166 |
|
52422M |
|
|
52424 |
120×250×177 |
|
52426 |
130(100)×270×192 |
|
52428 |
140(110)×280×195 |
|
52430 |
150(120)×300×209 |
|
52432 |
160×320×226 |
|
52434 |
170×340×236 |
|
52436 |
180×360×245 |
|
527/49 |
49(41)×78×63.41 |
|
527/88 |
88(74)×118×69.4 |
|
527/340 |
340(300)×400×80 |
|
52780 |
400(350)×440×70 |
|
527/615 |
615(570)×700×90 |
|
527/940 |
940(865)×1030×110 |
|
527/950.8M |
950.8(845)×1030×110 |
|
527/950.8/YB2 |
950.8(845)×1030×110 |
|
527/950.8/YA3 |
950.8(845)×1030×120 |
|
527/1181 |
1181(1070)×1280×145 |
|
527/1226 |
1226×1360×200 |
|
527/1300 |
1300×1600×235 |
|
527/1520 |
1520(1420)×1720×270 |
|
54226U |
130(100)×195×96 |
|
54307U |
37(30)×72×52 |
Last
Next
Last
53000 Series
Next
Advantages
The product is widely used as a supporting product in industries such as metallurgy, mining, petroleum, chemical, coal, cement, papermaking, wind power, heavy machinery, engineering machinery, agricultural machinery, port machinery, etc.
01
Suitable for mass production, with stable and reliable quality and high production efficiency
02
Standardized size, interchangeable, easy to install and disassemble, and easy to maintain
03
Compact structure, light weight, and reduced axial size
04
High precision, high load, low wear, and long service life
05
The starting friction torque is only slightly higher than the rotational friction torque
06
Suitable for mass production, with stable and reliable quality and high production efficiency
07
The transmission friction torque is much lower than that of hydraulic bearings, resulting in lower friction temperature rise and power consumption
08
Some bearings have automatic centering performance
