Product Series
5300E Series
Large Angular Contact Ball Bearing - Open, Double Row
Key words:
Category:
Angular Contact Ball Bearings
E-mail：
WhatsApp：
5300E Series
Large Angular Contact Ball Bearing - Open, Double Row
Two types of contact angles can be selected according to the magnitude of the axial load and moment load.
Similar to single-row deep groove ball bearings, with a seal (2NS) and shield (ZZ) attached.
Can be used on Blower, High-speed vacuum pump receiver, Supercharger and Two-wheeled vehicle transmission
|
Bearing Number |
d mm |
D mm |
Bmm |
|
5205 E |
25 |
52 |
20.6 |
|
5206 E |
30 |
62 |
23.8 |
|
5207 E |
35 |
72 |
27.0 |
|
5208 E |
40 |
80 |
30.2 |
|
5209 E |
45 |
85 |
30.2 |
|
5210 E |
50 |
90 |
30.2 |
|
5211 E |
55 |
100 |
33.3 |
|
5212 E |
60 |
110 |
36.5 |
|
5213 E |
65 |
120 |
38.1 |
|
5214 E |
70 |
125 |
39.7 |
|
5215 E |
75 |
130 |
41.3 |
|
5216 E |
80 |
140 |
44.4 |
|
5217 E |
85 |
150 |
49.2 |
|
5218 E |
90 |
160 |
52.4 |
|
5305 E |
25 |
62 |
25.4 |
|
5306 E |
30 |
72 |
30.2 |
|
5307 E |
35 |
80 |
34.9 |
|
5308 E |
40 |
90 |
36.5 |
|
5309 E |
45 |
100 |
39.7 |
|
5310 E |
50 |
110 |
44.4 |
|
5311 E |
55 |
120 |
49.2 |
|
5312 E |
60 |
130 |
54.0 |
|
5313 E |
65 |
140 |
58.7 |
|
5314 E |
70 |
150 |
63.5 |
|
5315 E |
75 |
160 |
68.3 |
|
5316 E |
80 |
170 |
68.3 |
Last
Next
Last
None
Next
Advantages
The product is widely used as a supporting product in industries such as metallurgy, mining, petroleum, chemical, coal, cement, papermaking, wind power, heavy machinery, engineering machinery, agricultural machinery, port machinery, etc.
01
Suitable for mass production, with stable and reliable quality and high production efficiency
02
Standardized size, interchangeable, easy to install and disassemble, and easy to maintain
03
Compact structure, light weight, and reduced axial size
04
High precision, high load, low wear, and long service life
05
The starting friction torque is only slightly higher than the rotational friction torque
06
Suitable for mass production, with stable and reliable quality and high production efficiency
07
The transmission friction torque is much lower than that of hydraulic bearings, resulting in lower friction temperature rise and power consumption
08
Some bearings have automatic centering performance
Processing Factory
We have a complete and scientific quality management system, equipped with modern production equipment and advanced testing instruments
